| Housing Material | PC & metal gripping rim | Strobe mode | Strobe |
| Solar panel |
18V, 10W single crystalline silicon solar cell, battery life≥15 years |
Flash frequency | 2/3Hz, 40 times/min, can be customized |
| Battery | 12V, 6AH rechargeable lithium battery(optional) | Duty Ratio | 1/3 |
| Shape&size | Φ300mm ，Φ400mm | Visual range | ≥1000m (at night) |
| Led Color | Yellow lamp 95 pieces，Yellow lamp 126 pieces | Brightness of one led | >4000mcd |
| Size | 350*350*150mm，450*450*250mm | Warranty | 12 months, from date of sale, providing not damaged by the user |
| Wavelength of led | 590~595nm(yellow), 625±5nm(red) | Working time | can work over 200 hours or 8 rainy days after fully charged |
| Normal life of led | ≥100000 hours | IP Grade | >IP54 |
| Rate of system | ≤4W | Standard | GB14887-2003, GA/T743-2007 China, can be customized |
| Work mode | 24hrs/day or light control (by switch) |
Advantage:
1.Simple to install. No need external power, no need wiring.
2.Energy saving. Low-power, solar cell, low cost
3.High light: Using import EPISTAR chip from TaiWan, high light and slow light decay.
4.Sturdy and durable. PC & Aluminum Cover, shock resistance, anti-aging, anti-corrosion
5.Stable performance. Use America ATMEL single ship to protect circuit
6.Long service life. Led ≥100000 hours, solar cell ≥15 years
7.Long working time.It can work over 200 hours or 8 rainy days after fully charged
Smart controller:
1.Defense of the charge protection. prevent electricity of battery to solar panel
2.Overcharge protection. prevent solar panel to overcharge battery
3.Overcharge protection. prevent a overcharge with the battery
4.Overload protection. it will turn off by itself when the electricity reach a 1.5 times of normal, and then work again about 1~2 min later
5.Temperature correction. it will modify the charge and discharge when there is a change of the temperature the battery
6.Recovery Interval: avoid its work shaking by the automatic -restoration characteristic of battery.Other protection. lightning protection, prevent the reverse connection etc
